Angus PE-100 Liquid Sample System Interface
Coriolis transmitter and prover interface with 10,000 pulses per barrel for proving and LACT applications.
The Angus PE-100 Liquid Sample System Interface provides a custom interface between Coriolis transmitters and both small- and large-volume provers. It gives the petroleum industry a simple, direct method of utilizing Coriolis meters in proving and LACT applications where multiple pulse outputs are required.
The PE-100 provides 10,000 pulses per barrel for proving and also provides a pulse per barrel for sampler and meter failure timers. Supplied in a NEMA 4X enclosure, the unit is designed for reliable field operation and straightforward integration into proving systems.
- Custom interface between Coriolis transmitters and small- to large-volume provers
- Designed for proving and LACT applications requiring multiple pulse outputs
- Provides 10,000 pulses per barrel for proving
- Provides a pulse per barrel for sampler and meter failure timers
- Four- and five-pin prover connections for onsite proving
- One dry contact and one 24VDC pulse output
- 11–30 VDC or 100–240 VAC power supply
- Supplied in a fiberglass hinged NEMA 4X enclosure
Technical Specifications
Product Type
Liquid Sample System Interface
Enclosure
Fiberglass hinged enclosure
Enclosure Size
10 x 8 x 6 in.
NEMA Rating
NEMA 4, 4X, 12
Weight
5 lb
Power Supply
100–240 VAC, 50–60 Hz, or 11–30 VDC
Max Current
1.6 A max
Primary Application
Coriolis meter proving and LACT applications
Prover Output
10,000 pulses per barrel
Pulse Outputs
One dry contact and one 24VDC pulse output
Prover Connections
Four- and five-pin prover connections
Connector Types
5-pin Switchcraft and 4-pin Amphenol
Included Connectors
Both connectors supplied with each unit
Ideal for Applications
Coriolis Meter Integration
LACT Systems
Meter Proving
Oil & Gas
Petroleum Sampling
PLC / RTU Integration
